Outlet / GFCI / Breaker Lookup
Search by room, device, or location to see the required protection and breaker size based on NEC 2023 general rules.
15A or 20A 125V dedicated circuit per NEC 210.11(C)(3)
At least one 20A branch circuit must be provided for bathroom receptacles. No other outlets on that circuit.
15A or 20A
Dwelling unit bedroom outlets must be AFCI protected.
20A 125V
Garage receptacles must be GFCI protected. Exceptions exist for dedicated non-readily accessible outlets.
15A or 20A
Hallway receptacles cannot be spaced more than 10 ft apart in a dwelling unit hallway.
15A or 20A 125V dedicated circuit
Dishwasher must be on a dedicated circuit and GFCI protected.
20A 125V small-appliance branch circuit
countertop receptacles require GFCI protection and must be served by 20A small-appliance branch circuits.
20A 125V dedicated circuit
Laundry area must have a dedicated 20A circuit.
15A or 20A 125V
Outdoor receptacles require GFCI protection and weather-resistant covers.
15A or 20A
Unfinished basement receptacles must be GFCI protected unless dedicated.
240V or 120V dedicated circuit per nameplate
Water heater must be on a dedicated circuit sized to nameplate rating.
Always verify requirements with your local Authority Having Jurisdiction (AHJ). NEC rules change, and local amendments may apply.
